多效蒸馏水机

摩门教的系列多影响水蒸馏器采用宫fied water as the feed water, manufacturing WFI by heating industrial steam. The produced WFI meets the requirements of CGMP (CP2010), USP34 and EP7.

1.Structural : pre-heater, condenser and the first effect evaporator are all double tube plate type.

2.Separation device: the feed water enters into the equipment will under three separation stages which is film downward evaporation, gravity separation and spiral circumferential flow.

3.Material: SS316L is adopted in parts that contact with the feed water, WFI and secondary pure steam.

4.Automatic welding: for the connection of the pipeline and the spare parts, arc welding is adopted to protect the automatic welding track, to ensure the welding quality.

5.Three-dimensional elbow: Making stainless steel pipe directly tensile bend in the pipeline as far as possible, avoid welding.

6.Insulation: Both the separator and pre-heater are adopted with glass fiber needle wire mat, which is a new type thermal insulation material. The insulation effect is 30 times better than the traditional material.

7.表面抛光：电 - 化学抛光被施加到内部和外部表面，从而有效地保证不锈钢的光洁度。喷砂处理，也可以采用向外部表面处理。

8。节能：多效蒸馏水具有工业蒸汽的利用效率高，因为二次蒸汽在每个效果使用，因此它有一个显著的节能效果。该节能显然是日益增加的NUM加剧ber of effect evaporators. At the same time, the amount of the cooling water is substantially reduced. The five-stage effect water distiller of WEMAC only use little cooling water, while the six-stage effect water distiller doesn’t need cooling water at all.

9.Automatic sterilization process after start, achieving the system self-sterilization process.

10。Control system: Adopt PLC automatic control technology, which can provide various modes of communication. And meet the control system of 21CFR PART11, the automatic control system can meet the requirement of GAMP5.

11.录音模式：无纸记录仪，或纸记录仪记录实时的关键参数。
